T4MAX 2.0W 24V

Inquire about this item

TECHNICAL SPECIFICATIONS

LED type

2835

Input

24V DC

Color temperature

7000 K

Beam angle

175º

Protection level

IP 67

Center-to-center distance

15.75"(400mm)

Working temperature

-22°F +122°F

Available colors

White

Light output

340 lm

Power

2 W

Installation depth	Distance between centers	Quantity per 1 sq.m.	Power per 1 sq.m.
3.9"(100 mm)	11.8"(300 mm)	12 pcs	24 W
5.1"(130 mm)	13.8"(350 mm)	9 pcs	18 W
6.3"(160 mm)	15.7"(400 mm)	9 pcs	18 W
7.9"(200 mm)	15.7"(400 mm)	9 pcs	18 W

TECHNICAL INFORMATION & LIGHT DISTRIBUTION GRAPH


LED type	2835
Input	24V DC
Color temperature	7000K
Beam angle	175º
Protection level	IP 67
Center-to-center distance	15.75"(400 mm)
Working temperature	-22ºF + 122ºF
Available colors	White
Power	2 W
Light output	340 lm

PRODUCT DIMENSIONS

PACKAGING & CONNECTION DIAGRAM

PACKING TIPE	CHAIN	PACKAGE	BOX
Quantity	20 pcs	100 pcs	500 pcs
Weight	1.2 lbs	6 lbs	30.34 lbs
